Riscv Virtual Machine

riscv is a computer architecture just like x86 or arm, the only difference is it's open, means any body could implement the spec and create a compatible hardware w/o the need of any licences or royalty costs. it's concederably simpler compared to x86 or arm, because the designers of this architecture learned a lot of lessons from existing ones, and were able to avoid many unnecessary complications in modern architectures. riscv is just a specification of the isa which is an abstract model that people could use to create a real cpu, or virtual machine that emulate it; so this is what I did, I made a software emulation layer that execute riscv instructions and provide io's to the programs.

github: https://github.com/noureddine-taleb/riscv-vm.git

the goal behind this project was to run linux on a vm. this emulator only supports a subset of the isa that is required to run linux; this implementation supports rv64 flavor with the following extensions I for instructions that manipulate integers, M for integer multiplication and division, A for atomic instructions (read-modify-write). also linux requires support for virtual memory (Sv39). this implementation also includes minimum support for pmp or physical memory protection, and interrupt handling code with couple io devices to have communication with the outside world namely a simple serial console (standard uart8250 implementation is in progress), and some standard auxilary hardware to handle external interrupts namely a plic to external interrupts, and clint for timer interrupts and interprocess communication.

1. Build

building the project is straight forward:

make

2. Run

the virtual machine is ready. the only missing part is the software. so we need a full system with a kernel and user programs to run on the vm, because the kernel will setup the environment, including io communication, and memory protection, then launches user space programs. for demo purposes you can just run the shipped in kernel:

make run

wait for the system to boot and you will get a shell:

custom image:

if you want to build your own kernel image follow these instructions:

your directory structure should look like after you setup all projects:

.
├── buildroot
├── linux
├── opensbi
├── config
├── core
├── devices
├── dts
├── helpers
├── include
├── kernel
├── main.c
├── Makefile
├── patches
├── README.md
└── soc

means all the cloning is done in the root directory.

a. rootfs

the rootfs contains the necessary programs to run in user space. we will use buildroot project for this to build an initramfs for the linux kernel.

download buildroot:

git clone --depth 1 --branch 2021.02.6 git://git.buildroot.net/buildroot buildroot

copy the config:

cp config/rv64_buildroot_config buildroot/.config

build:

(cd buildroot; make -j$(nproc))

b. Kernel

first of all we need rv64 cross compiler toolchain, checkout your distro package that has that, in my case it's archlinux:

doas pacman -S riscv64-linux-gnu-gcc

then we need to download the linux kernel source (torvalds tree):

git clone --depth 1 --branch v6.3 git://git.kernel.org/pub/scm/linux/kernel/git/torvalds/linux.git linux

copy the config:

cp config/rv64_linux_config linux/.config

build the kernel:

(cd linux; make ARCH=riscv CROSS_COMPILE=riscv64-linux-gnu- -j$(nproc))

c. opensbi

opensbi is a supervisor interface that run in machine mode and provides services for the supervisor (the kernel). it's like the firmware and it helps operating systems to access the soc services in a portable way.

download opensbi:

git clone https://github.com/riscv-software-src/opensbi.git opensbi

(cd opensbi; git checkout v1.2)

build:

(cd opensbi; make CROSS_COMPILE=riscv64-linux-gnu- PLATFORM_RISCV_XLEN=64 PLATFORM_RISCV_ISA=rv64ima_zicsr_zifencei PLATFORM=generic FW_PAYLOAD_PATH=../linux/arch/riscv/boot/Image)

d. run the image

the final image will have the following structure:

┌──────────┬───────────┬────────────────────┐
│          │           │                    │
│ opensbi  │   linux   │     buildroot      │
│          │           │                    │
└──────────┴───────────┴────────────────────┘

we also need the device tree:

make ./dts/rv64_dt.dtb

let's boot the vm:

./riscv-vm dts/rv64_dt.dtb ./opensbi/build/platform/generic/firmware/fw_payload.bin
